Ciri-ciri teknis:
1. Layar layar Inggris lan Cina, iku gampang kanggo operate.
2. Fungsi sistem komputer PLC luwih stabil, lan luwih gampang kanggo nyetel paramèter apa wae.
3. Bisa nyithak sepuluh dhaptar, lan gampang kanggo ngganti parameter.
4. Sever film motor gambar, sing apik kanggo lokasi akurat.
5. Sistem kontrol suhu indhektor, presisi akurat ± 1 ° C.
6. Horisontal, vertikal kontrol suhu, cocok kanggo macem-macem film komplit, PE film kemasan materi.
7. Packing diversifikasi tipe, sealing bantal, tipe berdiri, meninju dll.
8. Pembuatan tas, penyegelan, pengepakan, tanggal pencetakan ing siji operasi.
9. Kahanan omah sing tenang, kurang swara.
Proses Pangerjaan:
Feeding - Conveying - Weighting - Forming (Isi - Sealing) --Finish Products Conveying
Aplikasi & jinis tas
Iki otomatis granule mengisi mesin pengepakan can be equipped with different weight and filling system for various granule, packaging such as peanuts, candies, cookies, potato chips, snacks, candy, pistachio, rice, sugar, beans, lentil, dried fruit, pet food,small hardware ect.
Kantong Pane: Pillow / back sealing / flat pouch, 3/4 side sealing pouch, stick / triangle pouch, gusseted / quatro pouch, doypack.
Spesifikasi Mesin:
Packing material | OPP / CPP, OPP / CE, PET / PE (Komplek film etc) |
Ukuran tas | 200mm (L) |
Kacepetan pengepakan | 5-60 (tas / menit) |
Jembar maksimal film muter | 320mm |
Range ngukur | 150-800ml |
Konsumsi banyu | 0.65mpa |
Konsumsi gas: | 0.6m3 / min |
Tegangan | 220V / 50Hz |
Daya | 2.5KW |
Ukuran produk | 1067 (L) X1026 (W) X1288 (H) mm |
Bobot produk | 300Kg |
